High-voltage transformer testing requires safeguard measures to ensure insulation, control power supply cutoff, remove dirt and impurities, and protect power transformer testers. These measures ensure accuracy, personal safety, and proper control of the power system, insulation layer structure, and insulation protection.
High-voltage transformer testing is crucial for ensuring the accuracy of detection and personal safety. To improve the test effect of power transformers under high voltage, it is essential to ensure insulation. This insulation is crucial for the power transformer itself, as it affects the accuracy of detection and personal safety. To ensure insulation, it is necessary to control whether the power system is energized and standardize power supply cutoff. Additionally, dirt and other issues on the insulation layer structure must be removed to prevent interference. Insulation protection for power transformer testers is also crucial. By addressing these aspects, the test effect of high-voltage transformers can be improved.
Use | Power |
Phase | Three |
Coil Structure | TOROIDAL |
Coil Number | AUTOTRANSFORMER |
Other Attributes
Place of Origin | Shandong, China |
Brand Name | Jinshida |
Model Number | SCB11-30~1600/,S11-30~1600/ |
Input Voltage | 10kv |
Product name | |
Rated capacity | 400kVA |
Frequency | 50Hz/60Hz |
Standard | ISO9001: 2008 |
Name | High Fequency Transformer |
Rated voltage | 22KV |
Warranty | 24 Months |
Cooling Method | ONAN |
Capacity | 400kva |
Selling Units | Single item |
Single package size | 1260X820X1240 cm |
Single gross weight | 50.000 kg |
Product Paramenters
10 Rated Power (kVA) | High Voltage (kv) | Low Voltage (kv) | Connection symbol | No-load loss(W) | On-load loss(W) | No load current (%) |
30KVA | 6.3KV 15KV 22KV 25KV 33KV 10KV 11KV 20KV 35KV
| 0.4 | Ydn11 Yyno | 570 | 4300 | 0.4 |
50KVA | ||||||
80KVA | 680 | 5140 | 0.45 | |||
100KVA | ||||||
125KVA | 810 | 30800 | 0.4 | |||
160KVA | ||||||
200KVA | 980 | 7500 | 0.4 | |||
250KVA | ||||||
315KVA | 1150 | 10300 | 0.35 | |||
400KVA | ||||||
500KVA | 1360 | 12000 | 0.3 | |||
630KVA | ||||||
800KVA | 1640 | 145000 | 0.6 | |||
1000KVA | ||||||
1250KAV | 1950 | 19140 | 0.6 | |||
1600KVA | ||||||
2000KVA | 2340 | 22220 | 0.5 | |||
2500KAV |
Customized Various Models
Product Process
Product Accessories
Application
Our products can be used in various industries such as power industry, urban construction, ports, etc.
