The capacity of a transformer is governed by its load. Because it is impossible to forecast the load accurately, it is frequently chosen based on the projected maximum load. As a result of this choice, the capacity setting is commonly set too high, which has a negative impact on the power system's performance. If the transformer is selected for economic operation, the maximum economic load rate and the ratio of rated capacity to maximum load are computed with the assumption that the transformer's copper and iron losses are equal. Because the load is unpredictable, operating efficiency varies.
The capacity of a transformer is governed by its load. Because it is impossible to forecast the load accurately, it is frequently chosen based on the projected maximum load. As a result of this choice, the capacity setting is commonly set too high, which has a negative impact on the power system's performance. If the transformer is selected for economic operation, the maximum economic load rate and the ratio of rated capacity to maximum load are computed with the assumption that the transformer's copper and iron losses are equal. Because the workload is uncertain, the operational efficiency.
Use | Power |
Phase | Three |
Coil Structure | TOROIDAL |
Coil Number | AUTOTRANSFORMER |
Other Attributes
Place of Origin | Shandong, China |
Brand Name | Jinshida |
Model Number | SCB11-30~1600/,S11-30~1600/ |
Input Voltage | 10kv |
Product name | |
Rated capacity | 400kVA |
Frequency | 50Hz/60Hz |
Standard | ISO9001: 2008 |
Name | High Fequency Transformer |
Rated voltage | 22KV |
Warranty | 24 Months |
Cooling Method | ONAN |
Capacity | 400kva |
Selling Units | Single item |
Single package size | 1260X820X1240 cm |
Single gross weight | 50.000 kg |
Product Paramenters
10 Rated Power (kVA) | High Voltage (kv) | Low Voltage (kv) | Connection symbol | No-load loss(W) | On-load loss(W) | No load current (%) |
30KVA | 6.3KV 15KV 22KV 25KV 33KV 10KV 11KV 20KV 35KV
| 0.4 | Ydn11 Yyno | 570 | 4300 | 0.4 |
50KVA | ||||||
80KVA | 680 | 5140 | 0.45 | |||
100KVA | ||||||
125KVA | 810 | 30800 | 0.4 | |||
160KVA | ||||||
200KVA | 980 | 7500 | 0.4 | |||
250KVA | ||||||
315KVA | 1150 | 10300 | 0.35 | |||
400KVA | ||||||
500KVA | 1360 | 12000 | 0.3 | |||
630KVA | ||||||
800KVA | 1640 | 145000 | 0.6 | |||
1000KVA | ||||||
1250KAV | 1950 | 19140 | 0.6 | |||
1600KVA | ||||||
2000KVA | 2340 | 22220 | 0.5 | |||
2500KAV |
Customized Various Models
Product Process
Product Accessories
Application
Our products can be used in various industries such as power industry, urban construction, ports, etc.
